RM-1-MET is an advanced robust trinocular or biniocular materials microscope for reflected transmitted light using a 12V 50W Halogen light source and optional 6v 30W transmitted light

Supplied with a range of Planachromat objectives, (FN22) eyepieces & XY stage

RM-1-MET trinocular materials microscope with:-

• Trinocular phototube
• Wide-field 10x/22 eyepieces – one focusing with cross-line & scale graticule
• Quintuple nosepiece
• Built-in 12v 50W incident Kohler illumination (transmission also available)
• Planachromat 5x/0.10
• Planachromat 10x.0.25
• Planachromat 20x/0.40
• Planachromat 50x/0.65
• Also available:- 40x, 80x & 100x
• Mechanical XY stage with vernier scale
• Adjustable field and aperture diaphragms

RM-1-MET/T as above with additional:-

• 6v 30w halogen transmitted illumination
• Polariser & Analyser
